Kev tsis muaj

1) Cov kua dej haum: pob tshab, khoom lossis cov tshuaj Argrivity, miscabically nruab nrab, kaw hauv cov khoom rau dej

2) Kev Ceev Ceev: N≈2850 rpm

3) Cov kua kub tshaj plaws kub rau +35 degree

4) Cov ntsiab lus siab tshaj plaws ntawm cov nplej ntawm cov xuab zeb: 0, 25%

5) Ntau Tshaj Plaws Tshaj Tawm: 80 M

6) NEMA ntau thiab tsawg, thev taus rau nkhaus raws li ISO 9906

7) Khoom Noj: Ib Leeg-Phashas 220 ~ 240V / 50Hz, 60Hz

Peb -phas 380 ~ 415v / 50Hz, 60Hz

8) Qhov tsawg kawg nkaus sab hauv lub qhov dej uas siv: 3.5 nti (90 hli), kuj tseem tuaj yeem ua kom tau raws li qhov loj me uas haum rau cov twj tso kua mis

Kev Lag Luam Kev Lag Luam

Cov zis caliber 1 1 "~ g 1 1 / 4"

Cov.	Tus Qauv Qauv		Kev noj qab haus huv		Kev sib hloov ceev: n ≈ 2850 r / min
	1 ~ 220-240 v	3 ~ 380-415 v	Kw	Hp	M³ / H	0		0.6		1.2		1.8		2.4		3.0
					L / min	0		10		20		30		40		50
01	3.5sdm1.5 / 6	3.5sd1.5 / 6	0.25	0.33	H (m)	38		37		31		27		19		9
02	3.5sdm1.5 / 9	3.5sd1.5 / 9	0.37	0.5		57		55		46		40		28		14
03	3.5sdm1.5 / 13	3.5sd1.5 / 13	0.55	0.75		82		79		67		58		41		20
04	3.5sdm1.5 / 16	3.5sd1.5 / 16	0.75	1.0		101		97		82		71		50		24
05	3.5sdm1.5 / 22	3.5sd1.5 / 22	1.1	1.5		139		133		113		98		69		33
06	3.5sdm1.5 / 28	3.5sd1.5 / 28	1.5	2.0		177		169		144		125		88		42
Cov zis caliber 1 1 "~ g 1 1 / 4"
Tsis yog.	Tus Qauv Qauv		Kev noj qab haus huv		Kev sib hloov ceev: n ≈ 2850 r / min
	1 ~ 220-240 v	3 ~ 380-415 v	Kw	Hp	M³ / H	0	0.6		1.2		1.8	2.4	3.0		3.6		4.2
					L / min	0	10		20		30	40	50		60		70
01	3.5SDM2 / 5	3.5sd2 / 5	0.25	0.33	H (m)	34	32		30		28	24	20		16		13
02	3.5SDM2 / 8	3.5sd2 / 8	0.37	0.5		54	51		48		45	38	32		25		21
03	3.5SDM2 / 12	3.5sd2 / 12	0.55	0.75		81	77		72		67	57	48		39		31
04	3.5SDM2 / 14	3.5sd2 / 14	0.75	1.0		94	89		84		78	66	56		48		36
05	3.5SDM2 / 18	3.5SD2 / 18	1.1	1.5		121	116		108		100	88	72		65		43
06	3.5SDM2 / 23	3.5sd2 / 23	1.5	2.0		155	146		138		125	113	94		80		52

Cov zis caliber 1 1 "~ g 1 1 / 4"

Tsis muaj	Tus Qauv Qauv		Kev noj qab haus huv		Kev sib hloov ceev: n ≈ 2850 r / min
	1 ~ 220-240 v	3 ~ 380-415 v	Kw	Hp	M³ / H L / min	0	0.6		1.2		1.8		2.4	3.0		3.6		4.2		4.8
						0	10		20		30		40	50		60		70		80
01	3.5sdm3/5	3.5sd3/5	0.25	0.33	H (m)	28	27		26		25		22	21		18		15		11
02	3.5sdm3/9	3.5sd317	0.37	0.5		39	38		36		35		31	29		25		21		15
03	3.5sdm3 / 11	3.5sd3/11	0.55	0.75		61	59		56		55		49	46		39		33		23
04	3.5sdm3/3 / 13	3.5SD3 / 13	0.75	1.0		72	71		69		65		61	52		45		36		26
05	3.5sdm3/5 17	3.5sd3 / 17	1.1	1.5		94	92		91		83		77	68		60		48		35
06	3.5sdm3 / 22	3.5sd3 / 22	1.5	2.0		122	120		118		108		100	88		77		62		45
Cov zis caliber 1 1 / 4 "~ g 1 1 / 2"
Tsis muaj	Tus Qauv Qauv		Kev noj qab haus huv		Kev sib hloov ceev: n ≈ 2850 r / min
	1 ~ 220-240 v	3 ~ 380-415 v	Kw	Hp	M³ / H L / min	0	0.6	1.2		1.8		2.4	3.0	3.6	4.2		4.8		5.4	6.0
						0	10	20		30		40	50	60	70		80		90	100
01	3.5sdm4 / 4	-	0.25	0.33	H (m)	23	23	22		21		20	19	17	15		13		10	7
02	3.5sdm4 / 6	3.5sd4 / 6	0.37	0.5		35	34	33		32		30	29	26	23		20		15	11
03	3.5sdm4 / 8	3.5sd4 / 8	0.55	0.75		46	45	44		42		41	38	35	31		26		21	15
04	3.5sdm4 / 10	3.5sd4 / 10	0.75	1		58	56	54		53		51	48	44	38		33		26	18
05	3.5sdm4 / 14	3.5sd4 / 14	1.1	1.5		81	79	76		74		71	67	61	54		46		36	26
06	3.5sdm4 / 19	3.5sd4 / 19	1.5	2		110	107	103		100		96	91	83	73		62		49	35

Qhia txog cov khoom

1. Daim ntawv thov: Lub nqus nqus 380 volts yog siv rau cov khoom siv dej ntawm cov tsev nyob, kev ua liaj ua teb, muaj cov tsiaj dej.

2. Qhov chaw ntawm keeb kwm: Jiangsey, Suav

3. Ntawv pov thawj: ISO9001, ISO14001, ISO45001, CCC, CE, CE, RoHS, thiab lwm yam, thiab lwm yam, thiab lwm yam, thiab lwm yam.

4. Nqe: Kev cog lus

5. Cov khoom siv: tooj liab, hlau stainless, cam khwb cia hlau, thiab lwm yam.

6. Lub sij hawm them nyiaj: TT, LC, thiab lwm yam. (cog lus)

7. Hnub xa tawm: kis tau

8. Ntim: Export txheem

9. Rynok: Middle East, Africa, Asia, Tebchaws Asmeskas Qab Teb, Tebchaws Europe, North America, Ukraine, thiab lwm yam.

10. Kev lav: 1 Xyoo

11.MOQ: 500 pcs.

Peculiarities

1 Siv cov hlau loj-tsis haum stainless hlau ua cov khoom siv rau kev tsim khoom ntawm cov ncej thiab lub tsev twj tso kua mis, lub rooj ntsuas hluav taws xob me me ntawm cov corrosion ntawm corrosion tsis kam thiab lav qhov tshwj xeeb depability.

2 cov khoom lag luam zoo pub rau lub zog tseem ceeb dhau sijhawm thiab yog kev lag luam muaj txiaj ntsig rau cov neeg siv khoom uas saib xyuas kom muaj kev txhim kho kom ruaj khov. Tus kos valve tsim muab kev tiv thaiv ntxiv rau cov tsav tsheb hydraulic uas cuam tshuam los ntawm cov dej rov qab tam sim no thaum sib tsoo.

3 Lub tswv yim rau lub twj tso kua mis yog ua nrog qhov yog qhov tseeb thiab yog nruab nrog lub cev nqaij daim tawv hauv cov kab ke, yog li ua kom muaj kev ua tau zoo thiab tiv thaiv qhov xav tau kev saib xyuas nquag.

4 Muaj cov txheej txheem txias ntawm cov roj ntxiv cov kev pabcuam lub neej ntawm lub peev txheej nqus 380 volts, ua kom muaj txiaj ntsig zoo rau ntau xyoo.

Peb Cov Kev Pab

1) nruj me ntsis tswj ntawm cov khoom lag luam thiab lub sijhawm khoom xa tuaj yog qhov tseem ceeb tseem ceeb.

2) Peb muaj kev sib tw tshwj xeeb los muab cov nqi sib tw rau peb cov neeg siv khoom.

3) Rau txhua qhov kev thov, peb lav tau cov lus teb ua haujlwm tsis pub dhau 12 teev.

4) Peb muab OEM thiab ODM kev pab cuam kom txaus siab ntau yam kev xav tau ntawm cov neeg siv khoom.

5) Cov kev muab ntawm cov kev pabcuam tom qab -sales rau cov neeg siv khoom yog peb qhov tseem ceeb tshaj plaws.

Cov Lus Nquag Nug

Q: Koj puas tuaj yeem ua rau peb tus kheej lub ntim?

A: Yog lawm, koj tsuas yog yuav tsum muab tsim qauv ntim, thiab peb yuav ua qhov koj xav tau. Peb tseem muaj cov kws tshaj lij cov qauv tsim uas tuaj yeem pab koj nrog ntim tsim.

Q: Koj lub tuam txhab tsim muaj ntau yam khoom lag luam ntau npaum li cas?

A: Tam sim no peb muaj ntau tshaj 1000 hom khoom. Peb muaj cov txiaj ntsig OEM muaj zog, tsuas yog muab cov khoom tiag tiag uas koj xav tau koj lub tswv yim thiab peb yuav ua rau koj.

Q: Thaum twg kuv mam li tau txais tus nqi no?

A: Feem ntau peb yuav muab nqe lus tsis pub dhau 8 teev tom qab tau txais koj qhov kev thov.

Cim npe nrov: Kev sib nqus 380 volts, Tuam Tshoj tob twj 380 volts manufacturers, lwm tus neeg, Hoobkas

PUMPT 380 VOLLE
